T-Himalia
T-Himalia is a tiltable downlight with efficient technical lighting properties. The luminaire can be rotated 355° horizontally and tilted 80° vertically. T-Himalia is available in three sizes with different lumen outputs and good colour rendering. The luminaire is ideal for illuminating shops and shop windows, fitting rooms or for illuminating objects that need to be in focus.
Installation
T-Himalia is for ceiling installation. Mounting springs are included for installation. Downlight connection is direct or via through-wiring. Driver is separate and is connected to the downlight.
Armature
T-Himalia is available in three different sizes: Ø140×114 mm, Ø160×130 mm and Ø190×154 mm, and the luminaire is made of cast aluminium and weighs between 0.8 kg - 1.5 kg depending on size. T-Himalia has an IP20 rating and is impact resistant up to IK07. AC 220-240. Available in RAL9016 (white) and 9005 (black) as standard.
LED information
T-Himalia is available with Ra80 - 3000/3500/4000K, option Ra>90. Standard wattage from 15W-45W, and a beam angle of 15°/ 24° /38° /60° degrees depending on size selection.
Operational lifetime (L80B90) 50,000 hours at 25 degrees.
Light control
T-Himalia is available with On/Off, Triac dim, DALI, 0-10V, ZigBee and BLE control.
LED driver expected lifespan 100,000 hours. Luminaire certification is under CIE EN 60598 1-2 and including EN550 15/EMC.
| Model: | T-Himalia |
| Size: | Ø140 x 114 mm |
| mA/W: | Standard - 350mA/15W / 500mA/20W / 600mA/25W |
| Optics: | 15° / 24° / 38° / 60° beam angle - Adjustable 355° horizontal and 80° vertical |
| Ra / Kelvin: | Ra80/90 - 3000K / 3500K / 4000K |
| Assembly: | Recessed |
| IP / IK: | IP20 / IK07 |
| Colour: | Standard - RAL9005 / RAL9016 |
| Material: | Aluminium |
| Weight kg: | 0.8 kg |
| IEC62717 (L80B10): | >50,000h at 25 degrees |
| Connection: | Direct |
| Steering: | On/Off / Triac dimming / 1-10V / DALI / ZigBee / BLE |
| Starting current / Leakage current: | 7.6A peak – 182us / 0.42 mA |
| Standby power: | <0.5W |
| Flicker-free: | Pst LM: 0.000 / SVM: 0.002 |
| Fuse C10: | 43a fuse |
| Luminous flux: | 80-130lm/W |
| Model: | T-Himalia |
| Size: | Ø160 x 130 mm |
| mA/W: | Standard - 600mA/25W / 700mA/30W / 800mA/35W |
| Optics: | 15° / 24° / 38° / 60° beam angle - Adjustable 355° horizontal and 80° vertical |
| Ra / Kelvin: | Ra80/90 - 3000K / 3500K / 4000K |
| Assembly: | Recessed |
| IP / IK: | IP20 / IK07 |
| Colour: | Standard - RAL9005 / RAL9016 |
| Material: | Aluminium |
| Weight kg: | 1.1 kg |
| IEC62717 (L80B10): | >50,000h at 25 degrees |
| Connection: | Direct |
| Steering: | On/Off / Triac dimming / 1-10V / DALI / ZigBee / BLE |
| Starting current / Leakage current: | 7.6A peak – 182us / 0.42 mA |
| Standby power: | <0.5W |
| Flicker-free: | Pst LM: 0.000 / SVM: 0.002 |
| Fuse C10: | 43a fuse |
| Luminous flux: | 80-130lm/W |
| Model: | T-Himalia |
| Size: | Ø190 x 154 mm |
| mA/W: | Standard - 800mA/30W / 950mA/40W / 150mA/45W |
| Optics: | 15° / 24° / 38° / 60° beam angle - Adjustable 355° horizontal and 80° vertical |
| Ra / Kelvin: | Ra80/90 - 3000K / 3500K / 4000K |
| Assembly: | Recessed |
| IP / IK: | IP20 / IK07 |
| Colour: | Standard - RAL9005 / RAL9016 |
| Material: | Aluminium |
| Weight kg: | 1.5 kg |
| IEC62717 (L80B10): | >50,000h at 25 degrees |
| Connection: | Direct |
| Steering: | On/Off / Triac dimming / 1-10V / DALI / ZigBee / BLE |
| Starting current / Leakage current: | 7.3A peak – 188us / 0.25 mA |
| Standby power: | <0.5W |
| Flicker-free: | Pst LM: 0.024 / SVM: 0.003 |
| Fuse C10: | 32 per fuse |
| Luminous flux: | 80-130lm/W |
