T-Sport
T-Sport is a highly efficient and robust industrial luminaire. The luminaire is specially designed for lighting sports halls, warehouses and more where high ceilings and a large lumen package are required.
Installation
Luminaire for surface mounting on ceiling - also available for suspended in wire. Mounting brackets are included for installation. Luminaire is connected directly - through-wiring is possible. Driver is integrated in the luminaire.
Armature
T-Sport is available in two different sizes, 1205 x 107 x 64.8 mm / 1460 x 107 x 64.8 mm, is made of aluminium and weighs between 12.1 - 15.2 kg. The luminaire has a tightness class of IP20 and is impact resistant up to IK10. AC 220-240. T-Sport is available in RAL9016 (white) as standard.
LED information
T-Sport is available as standard 75-150W depending on luminaire size. See data sheet. Ra80 - 3000K or 4000K. 150 lm/W. Operational lifetime (L80B10) 50,000 hours at 25 degrees.
Light control
T-Sport is available with on/off or DALI control. Available with EasyAir sensor.
LED driver expected lifespan 100,000 hours. Luminaire certification is under CIE EN 60598 1-2 and including EN550 15/EMC.
| Model: | T-Sport |
| Size: | 1205 / 1460 x 107 x 64.8 mm |
| mA/W: | Standard - 2000mA/75W |
| Optics: | 40º / 60º / 90º / 120º beam angle - Option: anti-glare grid |
| Ra / Kelvin: | Ra80 - 3000K / 4000K |
| Assembly: | Surface mounted |
| IP / IK: | IP20 / IK10 |
| Colour: | Standard - RAL9016 |
| Material: | Aluminium |
| Weight kg: | 12.1 kg / 15.2 kg |
| IEC62717 (L80B10): | >50,000h at 25 degrees |
| Connection: | Direct / Through wiring |
| Steering: | On/Off / DALI |
| Starting current / Leakage current: | 15.5A peak – 198µs / 0.61mA |
| Standby power: | <0.5W |
| Flicker-free: | Pst LM: 0.017 / SVM: 0.001 |
| Fuse C10: | 20 amp fuse |
| Luminous flux: | 150lm/W |
| Model: | T-Sport |
| Size: | 1205 / 1460 x 107 x 64.8 mm |
| mA/W: | Standard - 2000mA/75W |
| Optics: | 40º / 60º / 90º / 120º beam angle - Option: anti-glare grid |
| Ra / Kelvin: | Ra80 - 3000K / 4000K |
| Assembly: | Surface mounted |
| IP / IK: | IP20 / IK10 |
| Colour: | Standard - RAL9016 |
| Material: | Aluminium |
| Weight kg: | 13.3 kg / 16 kg |
| IEC62717 (L80B10): | >50,000h at 25 degrees |
| Connection: | Direct / Through wiring |
| Steering: | EasyAir sensor |
| Starting current / Leakage current: | 24.9A peak - 215us / 0.4mA |
| Standby power: | <0.37W |
| Flicker-free: | Pst LM: <0.06 / SVM: 0.08 |
| Fuse C10: | 16 per fuse |
| Luminous flux: | 150lm/W |
| Model: | T-Sport |
| Size: | 1205 / 1460 x 107 x 64.8 mm |
| mA/W: | Standard - 1000mA/150W |
| Optics: | 40º / 60º / 90º / 120º beam angle - Option: anti-glare grid |
| Ra / Kelvin: | Ra80 - 3000K / 4000K |
| Assembly: | Surface mounted |
| IP / IK: | IP20 / IK10 |
| Colour: | Standard - RAL9016 |
| Material: | Aluminium |
| Weight kg: | 12.1 kg / 15.2 kg |
| IEC62717 (L80B10): | >50,000h at 25 degrees |
| Connection: | Direct / Through wiring |
| Steering: | On/Off / DALI |
| Starting current / Leakage current: | 31A peak - 420us / 1.8mA |
| Standby power: | <0.5W |
| Flicker-free: | Pst LM: 0.009 / SVM: 0.006 |
| Fuse C10: | 11 per fuse |
| Luminous flux: | 140lm/W |
40º beam angle
60º beam angle
70º beam angle - anti-glare grating
1205 / 1460mm
