T-Model C Ø60

T-Model C is in a product family with our popular T-Model C Ø170 and T-Model S. The product family is based on the classic cylinder shape, making the look timeless and future-proof. T-Model C Ø60 creates a great atmosphere from the city centre to the suburbs.

Installation

T-Model C Ø60 is for mounting on masthead Ø60 or Ø76. The luminaire is connected directly with a connection cable that is customised for each project.

Armature

T-Model C Ø60 measures Ø170 x 540 mm, is made of aluminium and PC diffuser and weighs 4 kg. The luminaire has an IP65 tightness rating and is impact resistant up to IK08. AC 220-240. The luminaire is available with both asymmetric II or symmetric V optics in polycarbonate. T-Model C Ø60 is available as standard in colour RAL7024.

LED information

T-Model C Ø60 is available as standard with On/Off, 1-10V, DALI, Dynadim (22:00 - 06:00, 50%) or Smartcity: Citylight / Sineco control. Connection of the luminaire is direct.

Light control

T-Model C Ø60 comes standard with Ra70/80 - 3000 or 4000 Kelvin. Standard wattage 30W / 40W or 50W. Lumen output up to 130lm/W. Operational lifetime (L90B10) 100,000 hours at 25 degrees.

LED driver expected lifetime 50,000 hours. Luminaire certification is under CIE EN 60598 1-2 & hereunder EN550 15/EMC

Model:	T-Model C Ø60
Size:	Ø170 x 540 mm
mA/W:	Standard - 30W / 40W / 50W
Optics:	Symmetrical - Option: Asymmetrical
Ra/Kelvin:	Ra70/80 - 3000/4000K
Assembly:	Top mounting on mast - Ø60 / 76 mm
IP:	65
Colour:	Standard - RAL7024
Connection:	Direct - cable
Steering:	DALI / 1-10V / Dynadim (22:00-06:00, 50%) or Smartcity
IEC62717 (L90B10):	100,000h at ta 25 degrees
Material:	Aluminium - PC shielding
Weight kg:	4kg
Fuse B16:	Standard - <48 per fuse
Luminous flux:	Up to 130lm/W

Data sheet

Lightfiles

Tender text

T2 lens

T5 lens

C-NODE NB-iot

C-NODE NB-iot sensor

C-Box

T-Model C Ø60, T-Model C Ø170 and T-Model S is a design product family based on the classic cylinder shape, making the look timeless and future-proof. With a product family like this, it is possible to mix and match the different street luminaires while maintaining the natural design thread.
